A systematic review and meta-analysis of the central innervation of the lower urinary tract 41
and confirmed the involvement of these key brain areas during micturition: the PMC, the PAG, thalamus, cingulate gyrus, prefrontal cortex, the insula and the cerebellum. Cluster 1 is a merged cluster covering the thalamus, PAG, PMC and the cerebellum. It has three obvious peak activations in the thalamus, PAG and PMC as shown in Fig 3. These current findings are in line with previous working models on the supraspinal networks supposed to be involved in micturition.1
S3 and S4 Tables show that all studies found multiple active clusters diffuse across the prefrontal cortex. Peak activations were found in all Brodmann areas within the prefrontal cortex, most of which were located in Brodmann areas 9 and 44. Both areas (the medial prefrontal cortex and the inferior frontal cortex) have been de- scribed previously to be involved in micturition.34,35 The variability of the exact activity location within these areas may result from the variety of different protocols applied in the included studies. The prefrontal cortex has strong connections with other limbic structures – the hypothalamus, amygdala, insula and cingulate gyrus and is known to be involved in the planning of complex cognitive behavior and ap- propriate social behavior.36 The voluntary decision when to void is generated in the prefrontal cortex in turn sending efferent signals via the cingulate to the PAG and PMC.1 The ALE analysis did not show an active cluster in the hypothalamus. However, two of the included studies did find such a cluster as shown in S4 Table.2,6 As the hypothalamus is part of the limbic system, its role in micturition has been described before.37 The size of the area is rather small, making detection of active clusters challenging.
Micturition vs PFMC
This systematic review studies the motor control of the LUT, consisting of one voluntary controlled task (PFMC) and one semi-voluntary controlled task (micturition). Although PFMC and micturition are both motor tasks of the LUT, they have completely different goals. Micturition is a complex coordinated process between the urinary bladder and the external urethral sphincter that aims to empty the bladder periodically, whereas PFMC is a more confined motor task. PFMC concerns the voluntary (M1) contraction on top of the involuntary tonic contraction of the urethral sphincter, which is responsible for urinary continence. The minimal overlap of activated brain areas was therefore expected and demonstrates this distinct working mechanism of the supraspinal organization of both tasks. Comparison of the results shows that only two clusters overlap: midcingulate gyrus (MCG) and the left thalamus. The important role of the MCG in reward-based deci- sion making has been described before,38 and involvement of this area was expected in both LUT motor tasks. The involvement of the basal ganglia was also expected in both tasks. The thalamocortical pathway is important in execution of motor tasks.39 But, the thalamus is also involved in interoceptive networks, and is therefore important in initiation of micturition.5
2
