                 40
Chapter 2
in the SMA during PFMC might lie in the posterior part of the SMA, which is close to the somatotopic location of activation in the primary motor cortex during PFMC. Further- more, Di Gangi Herms et al. showed that, after a training interval of 12 weeks regular PFMCs, the number of activated voxels on the SMA decreased significantly compared to before PFMCs training.28 This demonstrated that the SMA plays an important role in unconditioned motor tasks, like PFMC. Thus, PFMC being an unconditioned task might induce the appearance of large clusters on SMA, and together with its orientation in the posterior SMA, these clusters might be indistinguishable from activation in M1. This could be an explanation for the incongruent findings of the different studies on M1 or SMA.
To our knowledge, our study is the first to confirm the involved brain areas in pelvic floor motor control using an ALE-analysis (Fig 2), namely the: M1, SMA, prefrontal cortex (BA 6 & 9), cingulate gyrus, thalamus, supramarginal gyrus and the anterior lobe of the cerebellum. Putamen activation however, was found in 4 of the included studies,10,20,23,29 but not in our ALE analysis. A possible explanation might be that the coordinates of the peak activations are spread across the putamen and that this did not result in the formation of a cluster in the ALE analysis. The role of the putamen in LUT control has been confirmed earlier, as this structure plays an important role in the corticostriatal pathway which participates in motor action selection and coordination.30
The ALE analysis revealed two clusters (#7 and #8) covering the substantia nigra and the red nucleus: parts of the basal ganglia involved in motor tasks.31 Two studies contrib- uted to the formation of these clusters in the ALE analysis.20,22
Micturition
Micturition is a complex process, involving both voluntary and involuntary control regulated by a supraspinal network. Until 1996, all available evidence for supraspinal micturition control was obtained from animal studies in cats32 or from case reports of humans with lesions in the prefrontal cortex.33 Blok et al. were the first to show brain activation in humans during micturition using PET.2,6 However, the evidence in hu- mans is still limited, possibly due to the fact that this LUT motor task is complicated to study. This is caused by several reasons; 1) In case of BOLD fMRI, repeated captures of the event-related data are necessary to obtain a higher signal-to-noise ratio, which is hard to establish considering the complex (autonomic and somatic) control of micturition, 2) Involved brain areas lie relatively closely to each other in the brainstem (PMC/PAG/thalamus); distinguishing these areas requires high resolution imaging, 3) A significant number of subjects are not able to void in the scanner, possibly due to the involvement of the prefrontal cortex involved in decision making in social context.1 The current study describes all PET and fMRI evidence for supraspinal micturition control and included 8 studies with a total of 107 subjects. S3 Table shows all raw data obtained in the last three decades. Using ALE analysis, this study evaluated all evidence
